Automatic Sheeter Machine DFJ-1100B

Model Number : DFJ-1100B

Place of Origin : CHINA

MOQ : 1 SET

Payment Terms : T/T

Supply Ability : 10 SETS/MONTH

Delivery Time : 40 WORK DAYS

Packaging Details : WOODEN CASE

Prepress : Automatic Sheeter Machine

Max Cutting Width : 1100MM

Max Unwinding Diameter : 1500MM

Thickness Range of Paper : 50-600g

Max Sheeting Speed : 160cuts/min

Max Feeding Speed : 130M/Min

Cutting Length Range : 20-1500mm

Cutting Precision : ≤±0.2MM

Max Piling Height : 1100MM

Request for Air Source : 0.8Mpa

Total Power : 6KW

Gross Weight : 4.5T

Overall Dimension(LxWxH) : 7500X2000X1600MM

Contact Now

Automatic Sheeter Machine DFJ-1100B

DFJ-1100B Automatic Sheeter Machine is adopted to vertical cut and horizontal cut of the color printing complex film and paper rolling materials.The workable paper thickness is from 50-700gsm, With the machine,power,liquid,gas together, it has the features of synchronous generator (or actuating motor) controlling fixed length cut, electrooptical system tracing modification, rolling material hydraulic power hoist,operating platform automatic ascent and descent, automatic paper arrangement, high precision.

Automatic Sheeter Machine DFJ-1100B

Main Specification(Hydraulic Shaftless loading for option)

Model	DFJ-1100B
Max Cutting Width	1100MM
Max Unwinding Diameter	1500MM
Thickness Range of Paper	50-600g
Max Sheeting Speed	160cuts/min
Max Feeding Speed	130M/Min
Cutting Length Range	20-1500mm
Cutting Precision	≤±0.2MM
Max Piling Height	1100MM
Request for Air Source	0.8Mpa
Total Power	8KW
Gross Weight	4.5T
Overall Dimension(LxWxH)	7500X2000X1600MM
